The Imaging Source DMK 39GX548-Z20 Camera
Need Help Finding the Best Camera for Your Solution? Call (631) 254-2600
Engineered for flexible monitoring, this Z Series monochrome zoom camera pairs GigE with PoE and the Sony IMX548 Pregius S global-shutter sensor for 5 MP capture at up to 24 fps. The integrated 20x motorized lens (6.8 mm to 136 mm) delivers rapid wide-to-tele transitions, with automatic or manual focus and iris for precise control. Trigger and I/O inputs enable synchronized acquisition, and the 71×71×147 mm design installs cleanly in production and security workflows.
TECHNICAL INFORMATION:
- Vision Standard: GigE Vision
- Dynamic Range: 12 bit
- Resolution: 2,448×2,048 (5 MP)
- Frame Rate: 24 fps
- Video Output Format: 8-Bit Monochrome, 12-Bit Packed Monochrome, 16-Bit Monochrome
- Interface (Optical)
- IR-Cut Filter (removable)
- Sensor Type: CMOS Pregius S
- Sensor Specification: Sony IMX548
- Shutter: Global
- Format: 1/1.8 inch
- Pixel Size: H: 2.74 µm, V: 2.74 µm
- Focal Length: 6.8 mm (wide) to 136 mm (tele)
- F-Stop: 1.5 (wide) to 3.4 (tele)
- MOD: 1 cm (wide) to 90 cm (tele)
- Focus: Automatic and Manual
- Iris: Automatic and Manual
- Lens: Integrated
Quick Info for the The Imaging Source DMK 39GX548-Z20
| Camera Category: | Zoom |
|---|---|
| Camera Series: | Z Series |
| FPS: | 24 |
| Interface: | GigE Vision |
| Manufacturer: | The Imaging Source |
| Resolutions: | 5 MP |
| Scanning Mode: | Global Shutter |
