OPTOWL FL-CC2514-5M C Mount Lens
Need Help Finding the Best Lens for Your Solution? Call (631) 254-2600
25 mm C-Mount Lens Pentax C2514-5M(KP) / Ricoh FL-CC2514-5M - 1.4/25mm 5 Megapixel
Fixed focal length lens, high-resolution, compact 5 Megapixel lens, with locking screws for C- and CS- Mount cameras
Highest Resolution and Contrast
- compatible with pixel size 3,45μm, 5 megapixel on 2/3" cameras
- high resolving power of 140 lp/mm from centre to corners of the image
Reduced Distortion Down to a Minimum
- 1% or less
- suitable for image measurement
High Light Transmission
- fast aperture F1.4
- even contrast and resolution from the center to the corners of the image
- 40% increased light distribution
Compact and Robust
- 43mm diameter
- ideal for integration in highly developed machine vision systems
- stable design, robust and durable
- with locking and thumb screws
| Description | Fixed focal length lens, high-resolution, compact 5 Megapixel lens, with locking screws for C- and CS- Mount cameras |
TECHNICAL INFORMATION:
| Aperture: | 1.4 ~ 16 |
|---|---|
| Focal Length: | 25mm |
| Format : | 2/3 |
| Manufacturer: | OPTOWL |
| Mount: | C Mount |
| Resolution : | 5 MP |
| Ruggedized: | -- |
